Durakool’s automotive Special Function Plugin Relays bring intelligent control to 12V and 24V systems with compact, plugin convenience. From timers and flashers to safety interlocks and high-current jumper links, these modules give design engineers ready-made solutions for tasks that normally require additional electronics.
Supporting up to 100A loads and switching up to 145VDC, the special function plugin relays fit industry standard micro-ISO and mini-ISO sockets for fast integration and easy servicing. Built with robust contacts and automotive grade construction, they deliver reliable performance in demanding environments. Smarter functions, faster design, proven durability — all in a simple plug-in relay.
Ready to simplify your next design? Explore the full range of automotive special function plugin relays and find the ideal relay for your application.
| Features |  |  |  |  |  |
|---|---|---|---|---|---|
| Series | DG43A | DG43E | DG43F | DG44 | DG46 |
| Description | A standard plugin replacement, long life automotive indicator relay, with stable electronic timing. Complete with audible ticking and operating over wide voltages and in wide ranging temperatures. | A long life plugin LED flasher/indicator automotive relay with stable electronic timing. ELV compliant with a wide operating voltage and temperature range. A metal mounting bracket option is available. | A standard plugin replacement, long life automotive indicator relay, with stable electronic timing. Complete with audible ticking and operating over a wide voltage and temperature range. | A long life plugin LED flasher/indicator automotive relay with stable electronic timing. ELV compliant with a wide operating voltage and temperature range. A metal mounting bracket option is available. | Special function plugin seat & belt switch controller. Designed to ensure a vehicle driver cannot start a vehicle unless sitting down & the belt fastened in correct sequence. Fits industry standard Mini-ISO sockets with 6.35mm terminals. |
| Supplier | Durakool | Durakool | Durakool | Durakool | Durakool |
| Dimensions (L x W x H) mm | 30.5 x 30.5 x 39 | 28.4 x 28.4 x 39.7 | 30 x 30 x 39 | 25 x 34 x 37 | 30 x 30 x 39 |
| Contact Configuration | LED Flasher | LED Flasher | LED Flasher | LED Flasher | SPST-NO |
| Max. Switching Voltage | 15VDC | 15VDC | 15VDC | 15VDC | Dependant on supply voltage |
| Rated Current | 20A (150W max.) | 20A (30W) | 20A (150W max.) | 20A (150W max.) | 10A |
| Contact Material | AgSnO2 | AgSnO2 | AgSnO2 | AgCu | AgSnO2 |
| Coil Voltages | 12V, 24VDC | 12V, 24VDC | 11 – 15VDC, 22 – 30VDC | 11 – 15VDC, 22 – 30VDC | 12V, 24VDC |
| Fits Socket Type | DZ85AB Series | DZ85AB Series | DZ85AB Series | DZ85AB Series | DZ85AB Series |
| Datasheet | Download | Download | Download | Download | Download |
| Enquire | Enquire | Enquire | Enquire | Enquire | Enquire |
| Features |  |  |  |  |  |
| Series | DG82-JMPR | DG82T | DG85A-JMPR | DG85D-JMPR | DGR |
| Description | An automotive plugin jumper link replacing the relay contacts. It operates at high continuous DC current capacity. Its industry standard terminal arrangement fits micro ISO sockets. | An industry standard terminal, micro ISO plugin delay ON or delay OFF timer vehicle relay. Suited for engine ECU shut down timing, heated rear windows, sunroof motors & automotive alarm systems. Add a Durakool relay for high currents. | An automotive plugin jumper link replacing the relay coil. It operates at high continuous DC current capacity. Its industry standard terminal arrangement fits mini ISO sockets 6.35mm terminals. | An automotive plugin jumper link replacing the relay coil. It operates at high continuous DC current capacity. Its industry standard terminal arrangement fits macro ISO sockets 9.5mm terminals. | A compact automotive motor reverser, high current 12VDC, plug-in relay with simplified electrical connections. Easy mounting options and industry standard ‘fast on’ terminals, and optional brackets. |
| Supplier | Durakool | Durakool | Durakool | Durakool | Durakool |
| Dimensions (L x W x H) mm | 23.7 x 15.7 x 26 | 23.7 x 15.7 x 26 | 28.03 x 28.3 x 25 | 28.3 x 28.3 x 25 | 58 x 35 x 46.5 |
| Contact Configuration | Wire Link | SPST-NO, SPDT Timer | Wire Link | Wire Link | 2 x SPDT Reverser |
| Max. Switching Voltage | N/A | 16VDC | N/A | N/A | 30VDC (Current Dependent) |
| Rated Current | 40A | 5A | 40A | 100A | 80A / 60A |
| Contact Material | N/A | AgSnO2 | N/A | N/A | AgSnOInO |
| Coil Voltages | N/A | 12V, 24VDC | N/A | N/A | 12V, 24VDC |
| Fits Socket Type | DZ82AB series | DZ82AB series | DZ85AB Series | ||
| Datasheet | Download | Download | Download | Download | Download |
| Enquire | Enquire | Enquire | Enquire | Enquire | Enquire |
