Durakool offers a wide range of high quality Industrial Relays including direct DIN rail, chassis and socket mounting types. Many of the series conform to industry recognised footprints. Industrial Relays are generally suitable for applications such as HVAC, control panels, machine tools or heavy machinery, but are found in many other places, such as white goods.
Features
Series
D2RS
DB30
DE35
DG36
DI8
Description
A high voltage DC switching miniature industrial relay (saving DIN rail space) with a lockable test feature (not D2RG). Other options are no test lever and/or high voltage DC switching.
General purpose plug in relay, good inrush current resistance, to 50A/240VAC. Screw mount and PCB option, fast-on 6.35mm. Two and three pole versions. UL certified.
Miniature automotive and Industrial PCB mount relay rated 2 x 40A at 277VAC and >2mm contact gap (3mm optional). Specially designed for EV charging systems with optional, force guided, NC auxiliary monitoring contact. UL Approved.
General purpose chassis mount with 6.35mm fast-on terminals or PCB mounting double pole relay to 30A/277VAC. 4kV dielectric strength and 8mm creepage distance.
A general purpose plug in relay with good inrush current resistance. Flat insert connectors – fast-on 6.35mm. NO types have >3mm contact gap. Optional DIN rail or screw mount.
An industrial relay switching currents up to 6,600VA with good inrush current resistance. Wide range AC coils. Used in heaters, HVAC and motor controls. Screw, plug in or PCB terminals. DIN rail mounting options.
An industry standard footprint industrial relay with no hole terminal blades for better mounting in sockets. Integral LED (Red AC, Green DC coils). Locking press feature test lever (Blue DC, Red AC coils). Welded coil connections (not soldered) for greater reliability.
An industry standard footprint industrial relay with no hole terminal blades for better mounting in sockets. Integral LED (Red AC, Green DC coils). Locking press feature test lever (Blue DC, Red AC coils). Welded coil connections (not soldered) for greater reliability.
An industry standard footprint industrial relay with no hole on terminal blades for better mounting in sockets. Integral LED (Red AC, Green DC coils). Locking press feature test lever (Blue DC, Red AC coils). Welded coil connections (not soldered) for greater reliability.
Industrial latching, PCB mounting, DC relay switching currents up to 125A at 80VDC. SPST-NO configuration with an aux. contact monitoring the position of the main contact. Single coil – reverse polarity to switch contacts. Contact gap ≥1.5mm.
Industrial latching, PCB mounting, DC relay switching currents up to 110A at 60VDC. SPST-NO configuration with an aux. contact monitoring the position of the main contact. Single coil – reverse polarity to switch contacts. Contact gap ≥1.5mm.
Industrial latching, PCB mounting, DC relay switching currents up to 80A at 24VDC. SPST-NO configuration with an aux. contact monitoring the position of the main contact. Single coil – reverse polarity to switch contacts. Contact gap ≥1.5mm.
An industrial relay with no hole on terminal blades for better mounting in socket. Integral LED (Red AC, Green DC coils (A universal 24VAC coil version with yellow LED is available)). Locking test lever standard. Back EMF diode standard for DC coils. Welded coil connections.
An industrial relay with a range of options for integral LED (Red AC, Green DC coils), back EMF diode (DC coils), Flange or mounting. Compatible with industry standard sockets (plug in), and PCB mounting option.
An Industrial DPDT plug in relay with integral LED (Red AC, Green DC coils). A locking test lever is standard. The DC coil version has a yellow LED and a back EMF diode. Welded internal connections for greater reliability. PCB option.
